Features:
- Supports 10 & 12mm Glass.
- Engineered for Interior & Exterior Residential.
- Square tube size of 40 x 40 x 2mm.
- Post Wall Thickness is 2mm
- Material is SS316 for Satin & SS304 for Powder Coated Black.
- Provides 36″ high Railings for Stairs and both 36″ and 42″ high option for landing with installed handrail.
- Complies with the updated OBC min. run for a rectangular thread of 255mm, and a min height of 920mm height for exterior stairs by using min. 1″ [25mm] thick Handrail.
- Fully Welded Tube Supports with a solid Square Stem, with included Flat Handrail Attachment Plate.
- Fully welded 4″ solid cast Stainless Steel Base Plates with flat push-fit base plate covers.
- Includes Large Square Glass Clips secured by an M8 x 20 Stainless Steel Fastener through flow-drilled and tapped holes to the Posts.
- 10 and 12mm Gaskets included
Click Here to Download Imperial Drawing!
If you have any questions, please do not hesitate to Contact Us.
For further questions regarding technical information, please contact our Technical Dept. at engineering@euroeac.com.
