SSPFHHGWS HYDRAULIC HINGE GLASS TO WALL OR SQUARE POST – SATIN FINISH

Share this product

$447.83

Check availability near you

| In stock

| In stock

| Out of stock

N/A

6.700 lbs

SKU: SSPFHHGWS Category:

Product Description

Features:

  • Made of SS316.
  • Suitable for 10-15mm tempered glass.
  • Maximum door leaf weight: 65kg/pair.
  • Maximum door leaf width: 1000mm.
  • Self-closing at any door open angle.
  • Double action, maximum door open angle: 95°
  • Non-hold configuration.
  • Valve adjustment available for closing speed control.
  • Self-positioned when door reaches initial position.
  • Tested according to EN1154 (100,000 cycles).
  • Sold as a pair.

Download Installation Instructions & recommended glass cut-out.

Download Pool Fencing Requirements.

Download our Pool Fencing Brochure.



Glass unit weights as reference

GLASS SIZE 8mm 10mm 12mm 14mm
WEIGHT (kg/m2) 18.2 22.7 27.3 31.8



Max door size for hydraulic hinges with door height of 2030mm (80″)

GLASS SIZE 10mm 12mm 14mm
W (max door width) 1200mm 1000mm 850mm



For information on how to calculate the Glass Weight, click here to see the reference tables and sample calculation.
