Product Description
Features:
- Made of SS316.
- Suitable for 10-15mm tempered glass.
- Self-closing at any door open angle.
- Double action, maximum door open angle: 95°
- Valve adjustment available for closing speed control.
- Self-positioned when door reaches initial position.
- Maximum door leaf weight: 65kg/pair.
- Maximum door leaf width: 1000mm.
- Tested according to EN1154 (100,000 cycles).
- Sold as a pair.
Download Installation Instructions & recommended glass cut-out.
Download Pool Fencing Requirements.
Download our Pool Fencing Brochure.
Glass unit weights as reference
| GLASS SIZE | 8mm | 10mm | 12mm | 14mm |
| WEIGHT (kg/m2) | 18.2 | 22.7 | 27.3 | 31.8 |
Max door size for hydraulic hinges with door height of 2030mm (80″)
| GLASS SIZE | 10mm | 12mm | 14mm |
| W (max door width) | 1200mm | 1000mm | 850mm |
For information on how to calculate the Glass Weight, click here to see the reference tables and sample calculation.
